Regular price€3,799.00
/
  • EU Prices Include VAT

Size
Color
Options

IMPORT DUTIES AND TAXES

• Purchases may be subject to Import Duties or Tax which vary by your location.

• At check-out you pay Time Bicycles the price of the frame and shipping without any additional Import Duties or Tax added.

• Any Import Duties or Tax on your purchase will be due on delivery to the shipping carrier, who may charge an additional brokerage fee.

ADHX 45 COULD BE YOUR TIME IF:

  • Google Maps can't figure out where you are most of the time

  • What appears to be a vicious sock tan wipes off with a wet washcloth

  • You know exactly where that Forest Service road connects, and HIGHLY recommend it

  • You don't own a pump gauge that goes past 60psi

 Bio-Based DYNEEMA® Fiber is Lighter, Stronger, and Smarter

Dyneema®fiber is 15x stronger than steel at the same weight and is so light that it floats on water. The promise of integrating Dyneema® in carbon structures has been making headlines for years now, but to date, very few manufacturers have been able to incorporate the material. TIME is different‚ we aren't reliant on materials availability from large carbon prepreg manufacturers. By weaving our own braided carbon structures (BCS), we have been able to test strands of sustainable Bio-Based Dyneema® fibers since they first became available from DSM.

Frame Specs

ADHX 45 FRAME SPECIFICATIONS
FRAME MATERIAL
BCS Carbon Fiber - Dyneema® Enhanced
THRU AXLES
12x120x1.5mm Pitch F, 12x159x1.5 Pitch R
SIZES
XS, SM, MD, LG, XL
SEATPOST DIAMETER
ø27.2mm
FORK STEERER TUBE
Tapered 1-1/8" to 1-1/2"
SEATPOST CLAMP
Proprietary ADHX Alloy
HEADSET BEARINGS
Top and Bottom 1-1/2" (with internal routing compression ring)
SHIFTING
Compatible with Electronic and Standard Shifting Systems
WHEEL SIZE
700c/650b
FRONT DERAILLEUR
1X and 2X Wide Compatible with Integrated Single Cover and Drivetrain Conversion Kit
MAXIMUM TIRE WIDTH
  • 700x32-45c Gravel Tire
  • 650x50c Gravel Tire
  • (not all tire/rim combinations fit with adequate clearance - check for appropriate fit)
REAR DERAILLEUR
Standard Mount
BOTTOM BRACKET
PF BB386
BRAKE TYPE
Front and Rear Flat Mount Disc
DISC HUB STANDARD
12x100mm F, 12x142mm R
ROTOR SIZE
140/160mm with Adapter





Geometry
